کیستون Schneider مدل DCEKYSTS-WT

مشخصات کلی > category:CAT 5
مشخصات کلی > نوع کابل:STP
مشخصات کلی > مشخصات فنی:Plug retention force 14Kgf
(140N)
Plug reliability force 750cycle
Jack Contact Material Phosphor bronze 50µ” gold over 100µ” nickel plating
Conductor compatibility 22-26AWG solid cable
Standard color White
Propagation delay 2.5ns Max @1-100 MHz
Insulation resistance 500Mohm(min)@500 Vdc
Voltage rating 72Vdc max
Contact resistance 20mohm (max) per contact
Current Rating 1.5A max
